Land-based diesel generator set
China Diesel Generating Set for Reliable Power 1500kw/50Hz Yuchai Generator Set
China Diesel Generating Set for Reliable Power 1500kw/50Hz Yuchai Generator Set (1500KW/50HZ Yuchai generator set)
- Customization
- Available
- After-sales Service
- Enquiry
- Warranty
- Enquiry
Product Detail
Basic Info.
| Model NO. | 1500KW/50HZ Yuchai generator set | Ignition Mode | Electric Ignition |
| Speed | High Speed | Cooling Cylinder | Forced Cooling |
| Intake Pressure Impulse | Supercharged | Fuel | Diesel |
| Number of Strokes | Four-Stroke | Cylinder Arrangement Form | V |
| Number of Cylinders | 16 | Type | Electric Motor |
| Generator Set Displacement | 52.26L | Phase (Math. | 3 |
| Frequency | 50Hz | Unit Power | 1500W |
| Transport Package | Export Packaging | Specification | 5200*2200*2660/11500 |
| Trademark | YUCHAI | Origin | China |
| HS Code | 8502110000 |
Product Description
| Technical Parameter | |||||
| Genset model | YC1350GF | YC1500GF | YC1600GF | ||
| Prime power (KW/kVA) | 1350/1688 | 1500/1875 | 1600/2000 | ||
| Standby power (KW/kVA) | 1500/1875 | 1650/2060 | 1760/2200 | ||
| Rated voltage V | 400/230 | ||||
| Rated currency A | 2435.8 | 2706.4 | 2910 | ||
| Frequency | 50 | ||||
| Power factor | 0.8 | ||||
| Frequency drop % | ≤2 | ||||
| Steady state frequency band | ≤0.5 | ||||
| (For rated frequency) Transient frequency deviation % | 100%The sudden | ≤+10 | |||
| reduction power | |||||
| Sudden load power | ≤-7 | ||||
| Recovery frequency time ( s ) | ≤3 | ||||
| Steady state voltage deviation % | ≤±1 | ||||
| Transient voltage | 100%The sudden | ≤+20 | |||
| deviation% | reduction power | ||||
| Sudden load power | ≤-15 | ||||
| Voltage recovery time ( S ) | ≤3 | ||||
| Voltage unbalance degree % | ≤1 | ||||
| Genset dimension(mm)/Weight (kg) | 5200*2200*2660/11500 | 5250*2250*2660/12000 | 5250*2250*2660/12500 | ||
| Engine | Model | YC16VTD2270-D30 | YC16VTD2510-D30 | YC16VTD2700-D30 | |
| Prime power(KW) | 1520 | 1680 | 1805 | ||
| Standby power(KW) | 1672 | 1850 | 1985 | ||
| Brand/manufacture | YUCHAI | ||||
| Speed(r/min) | 1500 | ||||
| No. of Cylinder | 16 | ||||
| Cylinder arrangement | V | ||||
| Stroke | Four stroke | ||||
| Air intake mode | Turbocharged & Intercooled | ||||
| Fuel supply | Electronic control high pressure common rail | ||||
| Bore x stroke | 152×180mm | ||||
| Displacement | 52.26L | ||||
| Emission | No-roadT3 | ||||
