Industrial power equipment product display

Diesel Generator Set

Product Details

Review product information, specifications and application details, supported by HYLICO POWER product matching and export coordination.

Diesel Generator Set

China High-Performance Yuchai Yc12vtd Series Diesel Generator for Sale 1120kw @ 1500 R/Min

China High-Performance Yuchai Yc12vtd Series Diesel Generator for Sale 1120kw @ 1500 R/Min (Yuchai generator YC12VTD series 1120kW @ 1500 r/m)

Customization
Available
After-sales Service
Yes
Warranty
2000h

Product Detail

Basic Info.

Model NO.Yuchai generator YC12VTD series 1120kW @ 1500 r/mIgnition ModeElectric Ignition
SpeedSpeedCooling CylinderWater-Cooled
Intake Pressure ImpulseSuperchargedPiston MovementReciprocating
FuelDieselNumber of StrokesFour-Stroke
Cylinder Arrangement FormVNumber of Cylinders12-Cylinder
TypeElectric MotorDisplacement39.2L
Oil Capacity (L)370LCylinder Quantity-Bore×stroke12-152×180mm
EmissionT3Transport PackageExport Packaging
Specification4200kg, 4, 570 kgTrademarkYUCHAI
OriginChinaHS Code8502110000

Product Description

China High-Performance Yuchai Yc12vtd Series Diesel Generator for Sale 1120kw @ 1500 R/MinChina High-Performance Yuchai Yc12vtd Series Diesel Generator for Sale 1120kw @ 1500 R/MinChina High-Performance Yuchai Yc12vtd Series Diesel Generator for Sale 1120kw @ 1500 R/MinChina High-Performance Yuchai Yc12vtd Series Diesel Generator for Sale 1120kw @ 1500 R/MinChina High-Performance Yuchai Yc12vtd Series Diesel Generator for Sale 1120kw @ 1500 R/Min



Introducing the exceptional Yuchai generator YC12VTD series, delivering a formidable 1120kW at 1500 r/min. This powerhouse of engineering excellence epitomizes high performance and reliability, ensuring optimal functionality for all your energy needs.

Model YC12VTD1680-D30 YC12VTD1830-D30 YC12VTD1350-D30 YC12VTD1500-D30 YC12VTD2000-D30 YC12VTD2270-D30 YC12VTD2510-D30 YC16VTD2500-T300
Prime power 1120kW @ 1500 r/min 1120kW @ 1500 r/min 900kW @ 1500 r/min 1000kW @ 1500 r/min 1345kW @ 1500 r/min 1520kW @ 1500 r/min 1680kW @ 1500 r/min 1680kW @ 1500 r/min
Standby power 1120kW @ 1500 r/minn 1342kW @ 1500 r/min 990kW @ 1500 r/min 1100kW @ 1500 r/min 1480kW @ 1500 r/min 1672kW @ 1500 r/min 1850kW @ 1500 r/min 1850kW @ 1500 r/min
Introduction The YC12VTD-D30 engine is independently developed based on domestic and foreign advanced technologies of largeengines.Equipped with the high pressure common rail system, four-valvestructure,turbocharger,intercooler, etc. andoptimized and verified by the advanced combustion development technology of Yuchai, the engine is characterized by high energy efficiency, reliability, loading capacity and maintainability. The YC12VTD series engine is a self-developed product by Yuchai combining the advanced technology for large engines. The configurations, such as fourvalves,turbocharged intercooled, and common rail, are adopted for it; and it is optimized and verifiedthrough the advanced combustion development technology of Yuchai, and is characterized by energy-saving and environment-friendly, high reliability, strong loading capability and good maintainability. The YC12VTD series engine is a self-developed product by Yuchai combining the advanced technology for large engines. The configurations, such as fourvalves,turbocharged intercooled, and common rail, are adopted for it; and it is optimized and verifiedthrough the advanced combustion development technology of Yuchai, and is characterized by energy-saving and environment-friendly, high reliability, strong loading capability and good maintainability. The YC12VTD series engine is a self-developed product by Yuchai combining the advanced technology for large engines. The configurations, such as fourvalves,turbocharged intercooled, and common rail, are adopted for it; and it is optimized and verifiedthrough the advanced combustion development technology of Yuchai, and is characterized by energy-saving and environment-friendly, high reliability, strong loading capability and good maintainability. The YC12VTD series engine is a self-developed product by Yuchai combining the advanced technology for large engines. The configurations, such as fourvalves,turbocharged intercooled, and common rail, are adopted for it; and it is optimized and verifiedthrough the advanced combustion development technology of Yuchai, and is characterized by energy-saving and environment-friendly, high reliability, strong loading capability and good maintainability. The YC12VTD series engine is a self-developed product by Yuchai combining the advanced technology for large engines. The configurations, such as fourvalves,turbocharged intercooled, and common rail, are adopted for it; and it is optimized and verifiedthrough the advanced combustion development technology of Yuchai, and is characterized by energy-saving and environment-friendly, high reliability, strong loading capability and good maintainability. The YC12VTD series engine is a self-developed product by Yuchai combining the advanced technology for large engines. The configurations, such as fourvalves,turbocharged intercooled, and common rail, are adopted for it; and it is optimized and verifiedthrough the advanced combustion development technology of Yuchai, and is characterized by energy-saving and environment-friendly, high reliability, strong loading capability and good maintainability. The YC12VTD series engine is a self-developed product by Yuchai combining the advanced technology for large engines. The configurations, such as fourvalves,turbocharged intercooled, and common rail, are adopted for it; and it is optimized and verifiedthrough the advanced combustion development technology of Yuchai, and is characterized by energy-saving and environment-friendly, high reliability, strong loading capability and good maintainability.
Type Vertical, V-type, water-cooled, four-stroke Vertical, V-type, water-cooled, four-stroke Vertical, V-type, water-cooled, four-stroke Vertical, V-type, water-cooled, four-stroke Vertical, V-type, water-cooled, four-stroke Vertical, V-type, water-cooled, four-stroke Vertical, V-type, water-cooled, four-stroke Vertical, V-type, water-cooled, four-stroke
Induction system Turbocharged & Intercooled Turbocharged & Intercooled Turbocharged & Intercooled Turbocharged & Intercooled Turbocharged & Intercooled Turbocharged & Intercooled Turbocharged & Intercooled Turbocharged & Intercooled
Cylinder quantity-bore×stroke 12-152×180mm 12-152×180mm 12-152×180mm 12-152×180mm 12-152×180mm 12-152×180mm 12-152×180mm 12-152×180mm
Number of valve per cylinder 4 4 4 4 4 4 4 4
Displacement 39.2L 39.2L 39.2L 39.2L 39.2L 39.2L 39.2L 52.26 L
Fuel supply system Common Rail Electronically-control high pressure common rail Electronically-control high pressure common rail Electronically-controlled assembly pump Electronically-control high pressure common rail Electronically-control high pressure common rail Electronically-control high pressure common rail Electronically-control high pressure common rail
Starting mode Electronic Electronic Electronic Electronic Electronic Electronic Electronic Electronic
Compression ration 14:1 14:1 14:1 14:1 14:1 14:1 14:1 14:1
Fual consumption g/(kW·h) ≤0.3% ≤0.5%   ≤0.3% ≤0.3% ≤0.3% ≤0.3% ≤0.3%
Oil capacity (L) 210L 210L   215 L 215 L 280 L 280 L 310 L
Oil consumption g/(kW·h) ≤0.3% ≤0.5%   ≤0.3% ≤0.3% ≤0.3% ≤0.3% ≤0.3%
Noise Lw dB (A) ≤88dB(A) ≤88dB(A)   106.2dB(A) 106.2dB(A) 102dB(A) 102dB(A) 102dB(A)
Emission T3 T3 T3 T3 T3 T3 T3 T3
Applicable altitude (m) ≤1000 ≤1000 ≤1000 ≤1000 ≤1000 ≤1000 ≤1000 ≤1000
Engine dimension (L×W×H) (mm) 2988×2100×2192 2988×2100×2192   2240×1700×1950 2240×1700×1950 3500×2200×2470 3500×2200×2470 2765×1700×1945
Dry weight (kg) 4200kg 4200kg   4,570 kg






Since its esteemed founding in 1951, Guangxi Yuchai Machinery Group Co., Ltd., or Yuchai Group, has been a beacon of innovation and engineering supremacy. Located in the bustling Yulin, Guangxi Zhuang Autonomous Region, Yuchai Group stands as a titan in investment and financing management, with a steadfast emphasis on capital operations and asset preservation. As a prominent state-owned enterprise conglomerate, Yuchai Group boasts an extensive network of over 30 dynamic subsidiaries, each thriving under diverse ownership structures. With total assets amounting to an impressive CNY 41.7 billion and a workforce of around 16,000 dedicated professionals, Yuchai Group stands proudly as a leading internal combustion engine manufacturer in China. Their expansive product portfolio and industrial footprint span key strategic regions such as Guangxi, Guangdong, Jiangsu, Anhui, Shandong, Hubei, Sichuan, Chongqing, and Liaoning. With annual sales surpassing CNY 40 billion, Yuchai Group consistently leads the engine sales charts, reinforcing its reputation as an industry leader.



Yuchai Group stands among the elite, securing a coveted position in the top 500 Chinese enterprises and the top 500 Chinese manufacturers, achieving an outstanding rank of 10th among the distinguished Top 100 China Machinery Industry giants, proudly maintaining the 100th position among China's 500 most esteemed brands, with an extraordinary brand valuation exceeding CNY 57.2 billion. Esteemed as a national leader in corporate culture and ethics, Yuchai Group has been celebrated with accolades like the prestigious "President's Quality Award of Guangxi Zhuang Autonomous Region" and the distinguished "Nomination for China Quality Award." Additionally, Yuchai Group underscores its commitment to sustainability by releasing its sustainable development report for 13 consecutive years, demonstrating its dedication to continuous improvement and environmental stewardship.



Through relentless innovation in systems, technology, and management, Yuchai Group has reinforced its dedication to integrating global expertise and advancing core competitiveness. This strategic focus aims to establish three pivotal industry sectors: "Engine Manufacturing and Industry Chain," "Logistics and Supply Chain Service," and "New Energy Industry (Electric Power and Automobile) and Related Services." As a leader in engine research, Yuchai Group has pioneered engines that meet and exceed China IV, V, and VI emission standards, positioning itself at the forefront of the green revolution in the engine industry. It offers economically viable green power solutions, driving the global pursuit of sustainability forward.

Looking boldly towards the future, Yuchai Group is set to amplify its collaborative ventures both nationally and globally, refining industrial frameworks and leveraging the revitalization momentum of Guangxi's machinery industry. This visionary approach is crafted to guide the enterprise towards secure, sustainable growth, boosting core competitiveness. It aims to transform into an industrial powerhouse with a future valuation of CNY 100 billion, achieving comprehensive global distribution, and ultimately realizing its ambitious vision of becoming a "Customer-trusted Brand, World-class Enterprise," renowned for excellence, innovation, and a steadfast commitment to quality and customer satisfaction.
