Land-based diesel generator set

China Reliable Diesel Generator Sets for Power Plant 6300V

China Reliable Diesel Generator Sets for Power Plant 6300V (YC16VC Diesel Generator Set)

Customization: Available
After-sales Service: Enquiry
Warranty: Enquiry

Send inquiry hylicopower@126.com

Product Detail

Basic Info.

Model NO.	YC16VC Diesel Generator Set	Ignition Mode	Electric Ignition
Speed	High Speed	Cooling Cylinder	Intercooler
Intake Pressure Impulse	Supercharged	Fuel	Diesel
Number of Strokes	Four-Stroke	Cylinder Arrangement Form	V
Number of Cylinders	12-Cylinder	Type	Electric Motor
Generator Set Displacement	79.17L	Rated Voltage V	400/230
Frequency	50Hz	Fuel Supply	Electrical Regulation
Transport Package	Export Packaging	Specification	600025003080 /13600
Trademark	YUCHAI	Origin	China
HS Code	8502110000

Product Description

Technical Parameter
Genset model		YC1200GF	YC1350GF	YC1500GF	YC1700GF	YC1800GF
Prime power (KW/kVA)		1200/1500	1350/1688	1500/1875	1700/2125	1800/2250
Standby power (KW/kVA)		1350/1688	1500/1875	1650/2062	1800/2250	2000/2500
Rated voltage V		400/230
Rated currency A		2180	2450	2725	3067.3	3247.7
Frequency		50
Power factor		0.8
Frequency drop %		≤2
Steady state frequency band		≤0.5
(For rated frequency) Transient frequency deviation %	100%The sudden	≤+10
	reduction power
	Sudden load power	≤-7
Recovery frequency time ( s )		≤3
Steady state voltage deviation %		≤±1
Transient voltage	100%The sudden	≤+20
deviation%	reduction power
	Sudden load power	≤-15
Voltage recovery time ( S )		≤3
Voltage unbalance degree %		≤1
Genset dimension(mm)		600025003080	600025003080	600025003080	630025003080	680025003080
/Weight (kg)		/13600	/14600	/14800	/16500	/197000
Engine	Model	YC12VC2070-D31	YC12VC2270-D31	YC12VC2510-D31	YC12VC2700-D31	YC12VC3000-D30
	Prime power(KW)	1380	1520	1680	1805	2005
	Standby power(KW)	1520	1670	1850	1985	2206
	Brand/manufacture	YUCHAI
	Speed(r/min)	1500
	No. of Cylinder	12
	Cylinder arrangement	V
	Stroke	Four stroke
	Air intake mode	Turbocharged & Intercooled
	Fuel supply	Electrical regulation
	Bore x stroke	200×210mm
	Displacement	79.17L
	Emission	No-road T3

Founded in 1951, the prestigious Guangxi Yuchai Machinery Group Co., Ltd., endearingly called Yuchai Group, proudly anchors itself in the dynamic city of Yulin, located within the Guangxi Zhuang Autonomous Region. As a formidable force in investment and financing management, Yuchai Group serves as a shining example of capital operation and assets management excellence. This monumental state-owned enterprise boasts an impressive network of over 30 fully-owned, holding, and joint-stock subsidiaries. With total assets reaching an astounding CNY 41.7 billion, it is bolstered by a dedicated team of approximately 16,000 passionate employees. Yuchai Group is a prominent leader in the internal combustion engine manufacturing sector, offering an extensive and comprehensive range of products across the vast landscape of China. The company's strategic industrial presence is well-established in regions such as Guangxi, Guangdong, Jiangsu, Anhui, Shandong, Hubei, Sichuan, Chongqing, and Liaoning. With annual sales consistently exceeding CNY 40 billion, Yuchai Group has steadfastly maintained its position as the industry leader in engine sales, year after triumphant year.
Yuchai Group stands as a heralded frontrunner among the top 500 Chinese enterprises and manufacturing companies, taking pride in its esteemed position as 10th among the Top 100 China machinery industry companies. Furthermore, it holds a commendable rank of 100th among China's 500 Most Valuable Brands, with an impressive brand value surging past CNY 57.2 billion. Yuchai Group is revered as a national role model in company culture and ethical advancement. The company's trophy cabinet is adorned with numerous accolades, including the prestigious 'President's Quality Award of Guangxi Zhuang Autonomous Region' and a 'Nomination for the China Quality Award.' Remarkably, the company has been publishing its sustainable development report for an outstanding 13 consecutive years, reflecting its unwavering commitment to sustainable practices and its forward-thinking ethos.
Capitalizing on the power of innovation, Yuchai Group leads with brilliance in system, technological, and management innovation, ensuring its position at the forefront of industry advancements. The company intensifies its efforts to embrace global innovations and talent, enhancing its core competitiveness while channeling social capital into pioneering projects. These strategic initiatives drive the advancement of three primary industry sectors: 'engine manufacturing and industry chain,' 'logistics and supply chain service,' and 'new energy industry (electric power and automobile) and related services.' As a trailblazer in engine research, Yuchai Group has consistently been ahead of the curve, launching engines compliant with China IV, V, and VI emission standards, setting a benchmark for its peers. This leadership solidifies its pivotal role in the green revolution, delivering eco-friendly and cost-efficient power solutions to its valued users.
Yuchai engines proudly traverse the globe, reaching over 180 countries and regions across Asia, Europe, America, and Africa. With its headquarters strategically located in Yulin, Guangxi Zhuang Autonomous Region, Yuchai Group adeptly distributes its production bases throughout China. Moreover, the company has established influential joint R&D centers and marketing branches on a global scale. Showcasing remarkable achievements, Yuchai Group consistently achieves an impressive annual sales revenue exceeding 30 billion yuan, accompanied by an extraordinary engine output reaching 600,000 sets each year.
