Auxiliary Marine Engine(50HZ)

Product Details

Review product information, specifications and application details, supported by HYLICO POWER product matching and export coordination.

China Efficient Yuchai Marine Engine for Commercial and Recreational Vessels Yc16vcx Series

Auxiliary Marine Engine(50HZ)

China Efficient Yuchai Marine Engine for Commercial and Recreational Vessels Yc16vcx Series

China Efficient Yuchai Marine Engine for Commercial and Recreational Vessels Yc16vcx Series (YC16VCX Yuchai Marine Engine series)

Customization
Available
After-sales Service
Schedule
Warranty
Schedule
Send inquiry hylicopower@126.com

Product Detail

Basic Info.

Model NO.YC16VCX Yuchai Marine Engine seriesIgnition ModeElectric Ignition
SpeedHigh SpeedCooling CylinderWater-Cooled
Intake Pressure ImpulseSuperchargedPiston MovementReciprocating
FuelDieselNumber of StrokesFour-Stroke
Cylinder Arrangement FormLNumber of Cylinders16
TypeCombustion EngineOverall Dimensions3800mm*1966mm*2418mm
Engine Oil Capacity370LDisplacement121.98
CertificatesZc,CCS.Eiapp,China National 2 EsionsmisTransport PackageExport-Specific Packaging
SpecificationNet weight 12000KGTrademarkYUCHAI
OriginChinaHS Code8408100000

Product Description


YC16VCX,Marine propulsion engine,2426kW~2940kWPower range
YC16VCX is a V-type marine diesel engine developed on the basis of the mature model of 16VC marine engine. As an ideal supporting power for all kinds of ships and specific to the working conditions of inland transport ships and marine fishing boats, it is a new generation of marine power developed by Yuchai in combination with the advanced diesel engine technology of Germany, the United States and Japan and in full accordance with the development process for modern European engine

Yuchai owns 11 engine assembly lines and 169 test-run benches, including 20 test-run benches for gas engines. Yuchai meets both assembling and testing requirements for diesel engines (light, medium, heavy and large sizes) and gas engines,

Technical parameters
Item YC16VCX Series marine diesel engine
Model YC16VCX4000L-C20 YC16VCX3600L-C20 YC16VCX3300-C20
Cylinder quantity - bore/stroke 16-215×210
(mm)
DisplacementL 121.98
Number of valves per cylinder 4
Induction system Turbocharged & intercooled
Rated power/speed(kW(Ps)/r/min) 2940(4000)/1500 2646(3600)/1350 2426(3300)/1350
Overload power/speed(kW(Ps)/r/min) 3234(4400)/1548 2910.6(3960)/1393 2668.6(3630)/1393
Min. specific fuel consumption of external characteristicsg/kW.h ≤191
Certificates CCS,EIAPP,China II
Diemension(Length × width × height)(mm) 3800×1966×2418
Dry weight(kg) 12000
